MODO TEAM 29 ELITE

MODO

Find a dealer

RAMME

Carbon MTB Race Pro BF-MB03 High-Modulus

TRAVEL (F/R) (MM)

100

FORGAFFEL

DT Swiss OPM O.D.L. Tapered, 15mm, remote LO

SPRING/DAMPING SYSTEM

Air NCS/O.D.L. + remote LO

KRANKSÆT

Shimano XT FC-M8000 Hollowtech II 34T

BAGSKIFTER

Shimano XT RD-M8000-D GS Shadow Plus

SKIFTEGREB

Shimano XT SL-M8000 RapidFire Plus I-spec II

FREEWHEEL/CASSETTE

SunRace CSMX8 11-46T

KÆDE

KMC X11

BREMSER

Shimano XT BR-M8000 hydraulic disc brake

STYRFITTINGS

FSA No.42/48/ACB

fornav

DT Swiss 370 Straightpull IS 15x100mm

Bagnav

DT Swiss 370 Straightpull IS 12x142mm

Fælg

DT Swiss X 412 28H

Eger

Sapim Laser/Racer Black

DÆK

Schwalbe Racing Ralph/Rocket Ron Performance 29x2.10"

FREMPIND

ONE Race SuperFlat 31.8mm

STYR

ONE Race flat

SALDEPIND

ONE Race CRB

SADEL

Fi'zi:k Arione Donna

GEAR

1x11

størrelse

15.5"(S), 17.5"(M)

ROTOR DIAM (MM)

160/160

grip/tape

ESI Racer's Edge silicone grips

KRANKBOKS

Shimano BB-71-41A

VÆGT*

9.7 kg

* Bike and frame weights are based off Superior Bikes pre-production painted frames at the time of publication. Weights may vary in final production.

Show full specification

FRAME SIZE	15.5"(S)	17.5"(M)
A SEAT TUBE LENGTH (mm)	15.5"(S) : 393	17.5"(M) : 431
B EFFECTIVE TOP TUBE LENGTH (mm)	15.5"(S) : 584	17.5"(M) : 605
C SEAT TUBE ANGLE	15.5"(S) : 74°	17.5"(M) : 74°
D HEAD TUBE ANGLE	15.5"(S) : 70.5°	17.5"(M) : 71°
BBd BB DROP (mm)	15.5"(S) : 55	17.5"(M) : 55
E CHAINSTAY LENGTH (mm)	15.5"(S) : 432	17.5"(M) : 432
BB BB SHELL SIZE	15.5"(S) : Press Fit 92mm	17.5"(M) : Press Fit 92mm
HS HEAD TUBE SIZE	*15.5"(S) : BC 1-1/8" 1.5" / FSA NO.42/ACB**	*17.5"(M) : BC 1-1/8" 1.5" / FSA NO.42/ACB**
G HEAD TUBE LENGTH (mm)	15.5"(S) : 100	17.5"(M) : 110
SP SEAT POST DIAMETER (mm)	15.5"(S) : 27.2	17.5"(M) : 27.2
SC SEAT CLAMP DIAMETER (mm)	15.5"(S) : 31.8	17.5"(M) : 31.8
FD FRONT DERAILLEUR DIAMETER (mm)	15.5"(S) : Diect mount E-type / Side Swing	17.5"(M) : Diect mount E-type / Side Swing
SEATPOST LENGTH (mm)	15.5"(S) : 400	17.5"(M) : 400
STEM LENGTH (mm)	15.5"(S) : 60	17.5"(M) : 60
HANDLEBAR WIDTH (mm)	15.5"(S) : 700	17.5"(M) : 700
CRANK LENGTH (mm)	15.5"(S) : 170	17.5"(M) : 175
