XP 939

MTB RACE

Find a dealer

MATTE NEON RED/BLACK/DARK RED

MATTE SMOKY ALU/BLACK/TEAM RED

Cadre

Alu X6 Ultralite

TRAVEL (F/R) (MM)

100

Fourche

Rock Shox Recon RL, remote LO

SPRING/DAMPING SYSTEM

Air NCS/O.D.L. + remote LO

PÉDALIER

Shimano FC-MT600 36/26T

FRONT DERAILLEUR

Shimano XT FD-M8020

DERAILLEUR ARRIÈRE

Shimano XT RD-M8000 GS Shadow Plus

MANETTE DE VITESSE

Shimano SLX SL-M7000 RapidFire Plus

FREEWHEEL/CASSETTE

SunRace CSMS7 11-42T

CHAÎNE

KMC X11

FREINS

Shimano BR-M425 hydraulic disc brake

Jeu de direction

FSA Orbit 1.5E ZS No.57E

FRONT HUB

DT Swiss 370 Straightpull IS 15x100mm

REAR HUB

DT Swiss 370 Straightpull IS 12x142mm

RIMS

Weinmann U32 Disc Race 28H

SPOKES

Sapim Laser/Racer Black

PNEUS

Schwalbe Racing Ralph/Rocket Ron Performance 29x2.10"

POTENCE

ONE Race SuperFlat 31.8mm

CINTRE

ONE Race flat

TIGE DE SELLE

ONE Race

SELLE

Selle Royal Seta Performa

GEARS

2x11

15.5"(S), 17.5"(M), 19.0"(L), 21.0"(XL)

ROTOR DIAM (MM)

180/160

grip/tape

Selle Royal Comfort

BOTTOM BRACKET

Shimano BB-MT500

Total WEIGHT*

11.4 kg

* Bike and frame weights are based off Superior Bikes pre-production painted frames at the time of publication. Weights may vary in final production.

Show full specification

FRAME SIZE	15.5"(S)	17.5"(M)	19.0"(L)	21.0"(XL)
A SEAT TUBE LENGTH (mm)	15.5"(S) : 393	17.5"(M) : 431	19.0"(L) : 482	21.0"(XL) : 533
B EFFECTIVE TOP TUBE LENGTH (mm)	15.5"(S) : 586	17.5"(M) : 605	19.0"(L) : 626	21.0"(XL) : 646
C SEAT TUBE ANGLE	15.5"(S) : 74°	17.5"(M) : 74°	19.0"(L) : 74°	21.0"(XL) : 74°
D HEAD TUBE ANGLE	15.5"(S) : 70.5°	17.5"(M) : 71°	19.0"(L) : 71°	21.0"(XL) : 71.5°
BBd BB DROP (mm)	15.5"(S) : 55	17.5"(M) : 55	19.0"(L) : 55	21.0"(XL) : 55
E CHAINSTAY LENGTH (mm)	15.5"(S) : 434	17.5"(M) : 434	19.0"(L) : 434	21.0"(XL) : 434
F WHEELBASE (mm)	15.5"(S) : 1084	17.5"(M) : 1098	19.0"(L) : 1120	21.0"(XL) : 1351
BB BB SHELL SIZE	15.5"(S) : Press Fit 92mm	17.5"(M) : Press Fit 92mm	19.0"(L) : Press Fit 92mm	21.0"(XL) : Press Fit 92mm
HS HEAD TUBE SIZE	*15.5"(S) : BC 1-1/8" 1.5" / FSA NO.57E**	*17.5"(M) : BC 1-1/8" 1.5" / FSA NO.57E**	*19.0"(L) : BC 1-1/8" 1.5" / FSA NO.57E**	*21.0"(XL) : BC 1-1/8" 1.5" / FSA NO.57E**
G HEAD TUBE LENGTH (mm)	15.5"(S) : 100	17.5"(M) : 110	19.0"(L) : 120	21.0"(XL) : 130
SP SEAT POST DIAMETER (mm)	15.5"(S) : 27.2	17.5"(M) : 27.2	19.0"(L) : 27.2	21.0"(XL) : 27.2
SC SEAT CLAMP DIAMETER (mm)	15.5"(S) : 31.8	17.5"(M) : 31.8	19.0"(L) : 31.8	21.0"(XL) : 31.8
FD FRONT DERAILLEUR DIAMETER (mm)	15.5"(S) : Diect mount E-type / Side Swing	17.5"(M) : Diect mount E-type / Side Swing	19.0"(L) : Diect mount E-type / Side Swing	21.0"(XL) : Diect mount E-type / Side Swing
SEATPOST LENGTH (mm)	15.5"(S) : 400	17.5"(M) : 400	19.0"(L) : 400	21.0"(XL) : 400
STEM LENGTH (mm)	15.5"(S) : 60	17.5"(M) : 80	19.0"(L) : 90	21.0"(XL) : 100
HANDLEBAR WIDTH (mm)	15.5"(S) : 720	17.5"(M) : 720	19.0"(L) : 720	21.0"(XL) : 720
CRANK LENGTH (mm)	15.5"(S) : 170	17.5"(M) : 175	19.0"(L) : 175	21.0"(XL) : 175
