RÁM
Alu 6061.T6 Steps Semi-integrated battery SU21
VIDLICa
Rock Shox Reba RL-A7, Tapered,
PRUŽENie/TLMEnie
Solo Air/MotionControl + LO
Kľuky s prevodníkmi
Shimano FC-E8000-B 34T
ZADNý MeNIČ
Shimano XT RD-M8000 GS Shadow Plus
rAdenie
Shimano SLX SL-M7000 RapidFire Plus
KAZETA
SunRace CSMS8 11-46T
reťaz
KMC X11ET Turbo Power
BRZDY (P/Z)
Shimano BR-M6000 hydraulic disc brake
HLAVOVÉ SLOŽEnie
FSA SX (I/E) 1-1/8" / 1.5"
Predný náboj
Shimano HB-M6010-B CL 15x110mm
ZADNý NÁBOJ
Shimano FH-M6010-B CL 12x148mm
RÁFiKY
Weinmann Spike 35 Disc Race 32H
PLÁŠTe
Schwalbe Nobby Nic 29x2.65"
SEDLOVKA
Crankbrothers Highline dropper, 125mm travel
SEDLO
Selle Royal Seta Performa
VEľKOSť
17.0"(M), 19.0"(L), 21.0"(XL)
gripy
ONE MTB Lock-on dual density kraton-gel
DOBA NABÍJania (počet hodín)
5
BATéria
BT-E8010 Li-Ion 36V / 14Ah / 504Wh
ZADNÍ ODPRUŽENÍ
Rock Shox Monarch RT
MAXIMÁLNa RýCHLOSť
25km/h
MOTOR
DU-E8000 **BLDC 36V / 250W / 70Nm
E-Bike systÉm
Shimano STePS E8000 Middle Drive Unit
| velikost rámu |
17.5"(M) |
19.0"(L) |
21.0"(XL) |
|
A
SEAT TUBE LENGTH (mm)
|
17.5"(M) : 431 |
19.0"(L) : 482 |
21.0"(XL) : 533 |
|
B
EFFECTIVE TOP TUBE LENGTH (mm)
|
17.5"(M) : 602 |
19.0"(L) : 626 |
21.0"(XL) : 640 |
|
S
STACK HEIGHT (MM)
|
17.5"(M) : 616.1 |
19.0"(L) : 625.4 |
21.0"(XL) : 634.6 |
|
R
REACH (MM)
|
17.5"(M) : 431.2 |
19.0"(L) : 451.9 |
21.0"(XL) : 462 |
|
C
SEAT TUBE ANGLE (degree)
|
17.5"(M) : 74.5° |
19.0"(L) : 74.4° |
21.0"(XL) : 74.3° |
|
D
HEAD TUBE ANGLE (degree)
|
17.5"(M) : 67.5° |
19.0"(L) : 67.5° |
21.0"(XL) : 67.5° |
|
BBd
BB DROP (mm)
|
17.5"(M) : 40 |
19.0"(L) : 40 |
21.0"(XL) : 40 |
|
E
CHAINSTAY LENGTH (mm)
|
17.5"(M) : 440 |
19.0"(L) : 440 |
21.0"(XL) : 440 |
|
F
WHEELBASE (mm)
|
17.5"(M) : 1163.1 |
19.0"(L) : 1187.4 |
21.0"(XL) : 1201.7 |
|
HS
ROZMĚR HLAVOVÉ TRUBKY
|
17.5"(M) : IHS 1-1/8"-1.5" (FSA NO.9M/CUP/TH/NO.7B |
19.0"(L) : IHS 1-1/8"-1.5" (FSA NO.9M/CUP/TH/NO.7B |
21.0"(XL) : IHS 1-1/8"-1.5" (FSA NO.9M/CUP/TH/NO.7B |
|
G
HEAD TUBE LENGTH (mm)
|
17.5"(M) : 90 |
19.0"(L) : 100 |
21.0"(XL) : 110 |
|
SP
SEAT POST DIAMETER (mm)
|
17.5"(M) : 31.6 |
19.0"(L) : 31.6 |
21.0"(XL) : 31.6 |
|
SC
SEAT CLAMP DIAMETER (mm)
|
17.5"(M) : 34.9 |
19.0"(L) : 34.9 |
21.0"(XL) : 34.9 |
|
STEM LENGTH (mm)
|
17.5"(M) : 60 |
19.0"(L) : 60 |
21.0"(XL) : 60 |
|
DUA
DRIVE UNIT ANGLE (degree)
|
17.5"(M) : DU-E8000-1° |
19.0"(L) : DU-E8000-1° |
21.0"(XL) : DU-E8000-1° |
|
HANDLEBAR WIDTH (mm)
|
17.5"(M) : 740 |
19.0"(L) : 740 |
21.0"(XL) : 740 |
|
CRANK LENGTH (mm)
|
17.5"(M) : 175 |
19.0"(L) : 175 |
21.0"(XL) : 175 |
|
SEAT POST LENGTH (mm)
|
17.5"(M) : 400 |
19.0"(L) : 400 |
21.0"(XL) : 400 |
21.0"(XL)
19.0"(L)
17.5"(M)
* The recommendation covers most common body types. Always try the bike yourself at the nearest shop!
